ELIA TUBE MONO

Elia Tube Mono edition is a tube mic/line preamplifier with high-quality transformers.

Circuit design and engineering provide a very wide frequency response, high gain, extraordinary sonority and natural compression, making it ideal for all types of microphones and instruments.

Amplification is entirely tube-based, with only two triodes on each channel, controlled by high-quality components, Lundahl transformers and balanced input/output connections with floating ground, to guarantee high-performance signal processing and optimum audio fidelity.

Elia Tube Mono edition is a compact 1-channel preamplifier designed to satisfy both studio and stage users.

Technical data ELIA Tube mono

Class A mono tube preamplifier
Lundahl transformer-balanced inputs and outputs
1 XLR microphone input
1 DI jack 6.35 input
1 output1 XLR
48-volt phantom powering per channel with blue LED indicator
20dB attenuator per channel
Phase inversion per channel
Gain control (0 to 67dB)
5-LED Vu-meter output level display (-20 to 3dBVU)
Bandwidth 10Hz to 30kHz
Distortion <0.1% at 1Khz
DI input impedance 2.2 Mohms
Mic input impedance 10 Kohms
Output impedance 300 Ohms
1U rack format
Dimensions 250x44.5x483mm
Steel chassis
Black aluminum front panel
Internal power supply AC220-240 / 50-60Hz
Power consumption 15W
Hand-made in France
